EarthQuaker Devices

Spatial Delivery v3

Spatial Delivery v3

Regular price $269.00 CAD
Regular price Sale price $269.00 CAD
Sale Sold out
Shipping calculated at checkout.
In stock

We have this item in stock and ready to ship.

EarthQuaker Devices took the already cosmic, original Spatial Delivery and added six presets to store all those favorite settings, from dissonant sweeps to rhythmic auto-wah frequencies to oscillating robot gibberish. Find and save your favorite filtered frequency...forever! Or, for ten minutes, until you find six new favorites. They also added expression control after hundreds heck, thousands - of requests! The expression jack assignment can be saved and recalled in any of the slots, so that signature sounds are readily available with a quick tap of the switch. Save your settings confidently and quickly, no menu diving required!

For all the Spatial Delivery diehards, all of the funky, familiar features of the original are still in place. It boasts three modes - switchable Up Sweep, Down Sweep and Sample and Hold functions - along with Range, Resonance and Filter controls. Get some wild filter sweeps with the Up and Down modes and adjust the Range to control the sensitivity and reaction time of the envelope, altering the width of the frequency sweep. In the Sample and Hold mode, the Filter is controlled by random voltage and the Range controls the speed. The Filter can be crossfaded between high pass (counterclockwise), band pass (center) and low pass (clockwise) for a wide variety of voices. The Resonance control goes from zero to the brink of oscillation and adds more body and ring to the filter voice. EarthQuaker Devices dares you to try to find something funky and formidable that the Spatial Delivery can't do.


  • V3 update to the popular three-mode envelope filter with the added ability to save and recall six presets and user-assignable expression control
  • Range, Filter, and Resonance knobs dial in the sound in each of the 3 modes
  • Mode Up: Sweeps the filter up
  • Mode SH: The filter is controlled by random voltage and the Range controls the speed
  • Mode Dn: Sweeps the filter down
  • User-assignable expression control
  • Two global operating modes which are indicated by the color of the Save/Recall switch
  • True bypass
  • Silent relay-based switching with Flexi-Switch® Technology
  • Current Draw: 75 mA
  • Input Impedance: 500 kΩ
  • Output Impedance: 100 Ω
  • Dimensions: 5 x 2.625 x 2.125" (127 x 67 x 54mm)
  • Weight: 10.08 oz (285.76 g)
