8 filter modes available with meta CV scanning, famous zero-delay feedback Grand Terminal filters: 24DB/OCT TRANSISTOR LADDER, MS-20 12DB/OCT, 12DB/OCT LOW PASS GATE, 12DB/OCT RESONANT LOW PASS GATE, 12DB/OCT DJ ISOLATOR BIPOLAR VARIABLE FILTER, 12DB/OCT HIGH PASS STATE VARIABLE FILTER, 12DB/OCT BAND PASS STATE VARIABLE FILTER, COMB FILTER / RESONATOR.
Additional hi-pass filter in series quickly cuts the boomy low end.
Stereo image widener with adjustable all pass filter delay on Right output.
Built in post filter VCA for compact voice setup.
120 mA +12V
15 mA -12V
0 mA 5V
